The Lab Spray Dryer is an advanced laboratory scale drying system designed for research and development purposes. It efficiently converts liquid or slurry samples into fine, dry powders using rapid hot-air drying technology. This versatile machine is ideal for testing new formulations, optimizing production processes, and producing small batches for analysis.
Key Features:
-
Precise Control: Features adjustable temperature, airflow, and feed rate, allowing for precise control over the drying process to meet specific experimental needs.
-
Compact Design: The small, space-saving design makes it perfect for laboratories and pilot-scale applications, providing a high-performance solution without taking up valuable space.
-
Efficient Drying Process: Rapid drying ensures minimal product loss and maximum retention of properties, such as flavor, color, and nutritional content.
-
Stainless Steel Construction: Built with high-quality stainless steel, making it durable, easy to clean, and compliant with food, pharmaceutical, and chemical industry standards.
Applications:
-
Pharmaceuticals: Ideal for drying active pharmaceutical ingredients (APIs), drug formulations, and excipients.
-
Food Processing: Used for drying heat-sensitive foods, flavors, and nutritional powders.
-
Biotechnology: Suitable for producing dried bacterial cultures, enzymes, and other bioproducts.
-
Chemical Industry: Perfect for drying chemicals, pigments, and other sensitive materials that require gentle drying.
spec ZPG-25 ZPG-50 ZPG-80 ZPG-100 ZPG-150 ZPG-200 ZPG-300 evaporation capacity(kg/h) 25 50 80 100 150 200 300 process amount of material liquid(kg/h) 25-34 50-68 80-108 100-135 150-203 200-270 300-406 output of finished pcoduct(kg/h) 4.8-7.2 9.2-14 14.8-22.4 18.4-28 24-42 36.8-56.4 55-85 Solid content of material liquid( %) 18-30 Moisture content of finished product( %) 3-5 electric power(kw) 63 132 153 204 246 330 heat source Steam plus electricity The collecting method of the product and its efficiency Grade one or two, or three stage cyclone wet dust remover is greater than or equal to 95% automatic control meters and instruments indicator of non-air and exhaust air temperature temperature of air inlet(℃) 160-220 temperature of air outlet(℃) 80-100 L 7000 8000 9800 11000 12200 14100 15000 overal dimensions(mm) W 4000 5000 5700 6200 7000 7800 9000 H 6200 6900 8000 8900 10750 11900 13000
